ZRE151L-AHLDPW (2008)
Toyota Auris/Corolla (Jpp)
(0812- )6FS
EC60A,EC65A
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33230A - SHAFT ASSY, GEAR SHIFT FORK, NO.1 | ||||
| 33230-20050 |
NDE150,ZRE151..6FS |
1 | ||
| 33237 - HEAD, RELEASE | ||||
| 33231-52010 |
NDE150,ZRE151..6FS |
1 | ||
| 33237A - PIN, SLOTTED SPRING (FOR RELEASE HEAD) | ||||
| 90254-05001 |
NDE150,ZRE151..6FS |
1 | ||
| 33240 - BRACKET ASSY, REVERSE SHIFT ARM | ||||
| 33240-16020 |
NDE150,ZRE151,ZZE150 |
1 | ||
| 33240-20040 |
NDE150,ZRE151..6FS |
1 | ||
| 33240-20041 |
NDE150,NRE150,ZRE15#..6F *206 |
1 | ||
| 33240-20041 |
NDE150,NRE150,ZRE151..6F *201 |
1 | ||
| 33240-20041 |
NDE150,ZRE151..6FS |
1 | ||
| 33240A - SHAFT ASSY, GEAR SHIFT FORK, NO.2 | ||||
| 33240-20071 |
NDE150,NRE150,ZRE15#..6F *206 |
1 | ||
| 33240-52030 |
NDE150,ZRE151..6FS |
1 | ||
| 33240-20071 |
NDE150,NRE150,ZRE151..6F *201 |
1 | ||
| 33250B - SHAFT ASSY, GEAR SHIFT FORK, NO.3 | ||||
| 33250-52130 |
NDE150,ZRE151..6FS |
1 | ||
| 33251A - LEVER, SHIFT, INNER NO.1 | ||||
| 33251-52050 |
NDE150,ZRE151..6FS |
1 | ||
| 33251B - PIN, SLOTTED SPRING (FOR SHIFT INNER LEVER) | ||||
| 90254-05001 |
NDE150,ZRE151..6FS L=22 |
1 | ||
| 33252A - LEVER, SHIFT, INNER NO.2 | ||||
| 33252-52030 |
NDE150,ZRE151..6FS |
1 | ||
| 33252C - PIN, SLOTTED SPRING(FOR SHIFT LEVER INN NO.2) | ||||
| 90254-05001 |
NDE150,ZRE151..6FS |
1 | ||
| 33256 - LEVER, SELECT INNER | ||||
| 33256-52020 |
NDE150,ZRE151..6FS |
1 | ||
| 33256C - PIN, SLOTTED SPRING (FOR SELECT INNER LEVER) | ||||
| 90254-05001 |
NDE150,ZRE151..6FS |
1 | ||
| 33260 - SHAFT ASSY, REVERSE SHIFT FORK(MTM) | ||||
| 33260-52010 |
NDE150,ZRE151..6FS |
1 | ||
| 33261C - SHAFT, SHIFT & SELECT LEVER | ||||
| 33261-52130 |
NDE150,ZRE151..6FS |
1 | ||
| 33261L - BUSH, BIMETAL FORMED (FOR SHIFT & SELECT LEVER SHAFT) | ||||
| 90384-14008 |
NDE150,ZRE151..6FS NO.1 |
7 | ||
| 90384-16005 |
NDE150,ZRE151..6FS NO.2 |
2 | ||
| 33261L - BUSH, BIMETAL FORMED (FOR SHIFT & SELECT LEVER SHAFT) | ||||
| 90384-14008 |
NDE150,ZRE151..6FS NO.1 |
7 | ||
| 90384-16005 |
NDE150,ZRE151..6FS NO.2 |
2 | ||
| 33261L - BUSH, BIMETAL FORMED (FOR SHIFT & SELECT LEVER SHAFT) | ||||
| 90384-14008 |
NDE150,ZRE151..6FS NO.1 |
7 | ||
| 90384-16005 |
NDE150,ZRE151..6FS NO.2 |
2 | ||
| 33261L - BUSH, BIMETAL FORMED (FOR SHIFT & SELECT LEVER SHAFT) | ||||
| 90384-14008 |
NDE150,ZRE151..6FS NO.1 |
7 | ||
| 90384-16005 |
NDE150,ZRE151..6FS NO.2 |
2 | ||
| 33261L - BUSH, BIMETAL FORMED (FOR SHIFT & SELECT LEVER SHAFT) | ||||
| 90384-14008 |
NDE150,ZRE151..6FS NO.1 |
7 | ||
| 90384-16005 |
NDE150,ZRE151..6FS NO.2 |
2 | ||
| 33261L - BUSH, BIMETAL FORMED (FOR SHIFT & SELECT LEVER SHAFT) | ||||
| 90384-14008 |
NDE150,ZRE151..6FS NO.1 |
7 | ||
| 90384-16005 |
NDE150,ZRE151..6FS NO.2 |
2 | ||
| 33261L - BUSH, BIMETAL FORMED (FOR SHIFT & SELECT LEVER SHAFT) | ||||
| 90384-14008 |
NDE150,ZRE151..6FS NO.1 |
7 | ||
| 90384-16005 |
NDE150,ZRE151..6FS NO.2 |
2 | ||
| 33261L - BUSH, BIMETAL FORMED (FOR SHIFT & SELECT LEVER SHAFT) | ||||
| 90384-14008 |
NDE150,ZRE151..6FS NO.1 |
7 | ||
| 90384-16005 |
NDE150,ZRE151..6FS NO.2 |
2 | ||
| 33261L - BUSH, BIMETAL FORMED (FOR SHIFT & SELECT LEVER SHAFT) | ||||
| 90384-14008 |
NDE150,ZRE151..6FS NO.1 |
7 | ||
| 90384-16005 |
NDE150,ZRE151..6FS NO.2 |
2 | ||
| 33266C - PLATE, SHIFT INTER LOCK | ||||
| 33266-52040 |
NDE150,ZRE151..6FS |
1 | ||
| 33275C - BALL (FOR SHIFT DETENT) | ||||
| 90360-10003 |
NDE150,ZRE151..6FS |
3 | ||
| 33275C - BALL (FOR SHIFT DETENT) | ||||
| 90360-10003 |
NDE150,ZRE151..6FS |
3 | ||
| 33275C - BALL (FOR SHIFT DETENT) | ||||
| 90360-10003 |
NDE150,ZRE151..6FS |
3 | ||
| 33275E - SPRING, COMPRESSION (FOR SHIFT DETENT BALL) | ||||
| 90501-13088 |
NDE150,ZRE151..6FS NO.1 |
1 | ||
| 90501-13089 |
NDE150,ZRE151..6FS NO.2 |
2 | ||
| 33275E - SPRING, COMPRESSION (FOR SHIFT DETENT BALL) | ||||
| 90501-13088 |
NDE150,ZRE151..6FS NO.1 |
1 | ||
| 90501-13089 |
NDE150,ZRE151..6FS NO.2 |
2 | ||
| 33275E - SPRING, COMPRESSION (FOR SHIFT DETENT BALL) | ||||
| 90501-13088 |
NDE150,ZRE151..6FS NO.1 |
1 | ||
| 90501-13089 |
NDE150,ZRE151..6FS NO.2 |
2 | ||
| 33275F - PLUG (FOR SHIFT DETENT BALL) | ||||
| 90341-12004 |
NDE150,ZRE151..6FS |
3 | ||
| 33275F - PLUG (FOR SHIFT DETENT BALL) | ||||
| 90341-12004 |
NDE150,ZRE151..6FS |
3 | ||
| 33275F - PLUG (FOR SHIFT DETENT BALL) | ||||
| 90341-12004 |
NDE150,ZRE151..6FS |
3 | ||
| 33926 - LEVER, SHIFT INNER, FRONT | ||||
| 33926-52010 |
NDE150,ZRE151..6FS |
1 | ||
| 33926C - PIN, SLOTTED SPRING(FOR SHIFT INNER LEVER) | ||||
| 90254-05001 |
NDE150,ZRE151..6FS |
1 | ||
| Common parts | ||||
| 91551-80820 | ||||
